AMS NEVE

88R LBEQ

500 Series Preamps

500-series EQ module, 4-band parametric control, ±20 dB gain, adjustable Q, low noise, high headroom, true-bypass, VPR Alliance compatible.

Shipping calculated at checkout.
Talk to our experts
Our team of experts is here to support you.

Delivery & Shipping

Free Shipping in Canada with orders over $200. Conditions apply. View details here.

Financing

Affirm

Break your purchase into easy monthly payments, quick approval and no hidden fees.
Click here for more info.

Equilease

Ideal for larger purchases, Equilease offers customized leasing solutions to fit your business needs.
Click here for more info.

Returns & Policy

You can review our terms and conditions here

Description

The Neve 88R LBEQ captures the character and precision of the renowned 88RS console in a single-slot 500-series module. Designed and built in England, this unit delivers the same sonic clarity, musical response, and tonal control found in Neve’s flagship large-format consoles. It brings studio-trusted equalisation to modular workflows, offering flexibility for a wide range of mixing and production styles.

This fully parametric EQ includes four independent bands, each with ±20 dB of gain, overlapping frequency ranges, and variable Q. From shaping low-end impact to refining high-frequency detail, the 88R LBEQ provides accurate and musical tone shaping. Switchable bell and shelf modes, including resonant shelving, allow for detailed adjustments across the spectrum. The true bypass feature supports easy comparison of processed and unprocessed signals. The 88R LBEQ functions effectively on its own or as part of a modular Neve signal chain with matching preamp and compressor modules.

Features

Authentic Console EQ Sound
Delivers the same tonal precision and musical response as the flagship Neve 88RS console.

Compact 500-Series Format
Fits into a single slot in any standard 500-series rack for easy studio integration.

Four Fully Parametric EQ Bands
Provides low, low-mid, high-mid, and high bands with complete control over gain, frequency, and Q.

Powerful Tonal Shaping
Each band offers ±20 dB gain and overlapping frequency ranges to handle subtle to bold adjustments.

Switchable EQ Modes
Low and high bands include selectable bell, shelving, and resonant shelving options for flexible tone control.

True Bypass Switching
Easily compare processed and unprocessed signals with a dedicated EQ on/off switch.

Smooth and Musical Response
Designed for minimal phase shift and natural-sounding results across the entire frequency spectrum.

Trusted by Top Studios
Based on the EQ found in studios like Abbey Road and AIR, known for reliable, world-class performance.

Part of the 88R Series
Pairs seamlessly with the 88R LB preamp and 88R LBC compressor for a complete Neve signal chain.

Simple Installation
Installs easily into a powered 500-series chassis—no tools or calibration required.

Specifications

General Specifications
Device Type: 4-Band Fully Parametric EQ
Compatibility: 500-Series / VPR Alliance Chassis
Circuit Design: Based on Neve 88RS Console EQ
Control Interface: Analog, with illuminated switches and push-pots
Construction: Designed and Built in England by AMS Neve
Form Factor: Single-Slot 500-Series Module
Dimensions: 132 mm (H) x 38 mm (W) x 145 mm (D)
Weight: 0.57 kg (1.26 lbs)

Equalisation Bands
EQ Bands: 4 (Low, Low-Mid, High-Mid, High)
Gain Range (All Bands): ±20 dB

Low Frequency Band
Frequency Range: 33 Hz – 440 Hz
Q Range (Bell Mode): 0.7 (Low Q) or 1.8 (High Q)
Modes: Bell, Standard Shelf, Resonant Shelf
Shelf Mode Switching: Via HF Gain push-switch and HF kHz push-switch

Low-Mid Frequency Band
Frequency Range: 120 Hz – 2 kHz
Q Range: 0.3 – 7 (continuously variable)

High-Mid Frequency Band
Frequency Range: 800 Hz – 9 kHz
Q Range: 0.3 – 7 (continuously variable)

High Frequency Band
Frequency Range: 1.5 kHz – 18 kHz
Q Range (Bell Mode): 0.7 (Low Q) or 1.8 (High Q)
Modes: Bell, Standard Shelf, Resonant Shelf
Shelf Mode Switching: Via LF Gain push-switch and LF kHz push-switch

Input/Output
Input Impedance: ≈24 kΩ
Output Impedance: ≈50 Ω

Performance
Headroom: +27.2 dBu @ 1 kHz (0.1% THD)
THD+N: <0.004% @ +10 dBu (20 Hz – 40 kHz)
Noise: –88 dBu (–117 dBu bypassed)
Dynamic Range: >107 dB
Frequency Response: ±0.1 dB (20 Hz – 20 kHz)

Power
Power Draw: <145 mA
