Console 32Classic 24 canaux, inclut Dante

Iconic Harrison Analog Tone
Features transformer-balanced mic preamps and the acclaimed 32C four-band EQ with smooth high-pass and low-pass filters for warm, musical sound.

24 Analog Input Channels
Well-balanced configuration ideal for tracking and mixing in mid-sized studios, offering expanded channel count with Harrison’s signature analog sound.

Built-In Dante Interface
Includes 64-channel premium AD/DA converters and fully integrated Dante AoIP system, allowing direct digital routing to and from your DAW or network without external hardware.

Hybrid Signal Flow Options
Supports both in-line and split monitoring workflows, with dedicated playback routing, cue feeds, and flexible DAW integration via Dante.

Full Bus & Routing Flexibility
Provides 8 multitrack buses, 4 mono aux sends, 1 stereo cue send, transformer-balanced main mix outputs, insert points, and direct outputs.

Atmos Monitoring Support
12-wide monitoring section designed for immersive formats including Dolby Atmos 7.1.4, with level control over all surround outputs.

Ergonomic, DAW-Friendly Design
DAW keyboard, trackball, and monitor placement supported with a deep front bolster and rear shelf, optimized for hybrid studios.

Professional Control Surface
Includes 100mm faders, full 20-segment metering, fader lock function, LED indicators, mute, solo, and precision monitoring control.

Silent, Efficient Operation
Fanless power supply, low heat design, and robust aluminum chassis ensure reliability and quiet operation in studio environments.

Built-In Instrument Input & Talkback
Front-panel instrument input for quick overdubs and an integrated talkback system with flexible routing to cue and monitor paths.

General Specifications
Harrison 32Classic 24-Channel Analog Console with Integrated Dante
Hybrid analog console with built-in Dante AoIP interface and AD/DA conversion
Designed for high-end music, post, and immersive audio studios
Classic Harrison 32C analog signal path with modern DAW and network integration
Fully modular design with premium transformer-balanced circuitry
In-line or split signal flow architecture
Fanless, low-heat internal power supply

Channel Count & Configuration
24 Mono Input Channels (transformer-balanced mic/line inputs)
Each channel includes:
– Classic Harrison 32C 4-band parametric EQ (Proportional-Q design)
– Switchable shelf/bell curves on high and low bands
– Variable High-Pass and Low-Pass Filters
– Balanced Line Input
– Balanced Insert Point
– Balanced Direct Output
– In-line/Playback signal routing with dedicated switch
– 100 mm premium fader with mute and solo
– 20-segment input LED meter
– Zero Fader Lock switch for unity gain routing
– Bus and Main Mix assignment with individual pan switches

Routing & Bussing
8 Multitrack Buses (assignable as mono or stereo pairs)
4 Mono Auxiliary Sends
1 Stereo Auxiliary Send
Stereo Cue Send
Transformer-balanced Main Mix Output
Main Mix and Bus Insert Points
Balanced Stereo Return Path with individual L/R level, mute, solo
Bus Master faders with insert, pan, mute, solo, 0 dB lock, and LED meters

Monitoring & Metering
12-Wide Atmos Monitoring Section (Dolby Atmos 7.1.4 capable)
Main Monitor Output
Alternate Monitor Output
Headphone Output
Sources: Main Mix, 2x External Stereo Inputs, External 7.1.4 Surround, Dante Stereo
Large Monitor Level Control with Dim, Mono, L/R Mute, Master Mute
Main Mix analog VU meters
LED Solo Active Indicator
20-segment LED meters on input and bus channels

Integrated Dante AoIP System
Built-in dual Dante 32×32 interfaces (96 kHz), combined into single network output
Total 64 channels of premium AD and DA conversion
Channel I/O and Bus/Monitor I/O separated internally
Internal Ethernet switch for single-cable DAW connection
Console appears as two devices on Dante Controller
Patchless routing, low-latency operation, full DAW integration
Playback input selectable per channel via internal DA from Dante

Foldback / Cue Matrix
3 Foldback / Cue Stereo Outputs
Matrix source selection per output: Aux Sends, Bus Outputs, Stereo Return, External Inputs, Main Mix
Level, Mute, Solo, 0 dB Lock switches per cue output
Dedicated Talkback Mic with master gain and All Talk control

Instrument & Utility Inputs
Instrument Input (Hi-Z / Mic switchable) on Monitor Module
Selectable on any Input Module
Includes Gain, 48V Phantom, -20 dB Pad, Main Mix Assign
Input Meter with LED

EQ & Processing
Classic 32C EQ with wide overlapping frequency bands
All bands use Proportional-Q design
Hi/Lo bands switchable between bell and shelving curves
Dedicated switchable HP and LP filters per channel

Modular Design & Construction
Fully modular with removable input and master sections
Double-sided PCBs with robust ground plane
Gold-plated switches and conductive plastic potentiometers
PCB-based summing architecture (no ribbon cables)
Standard D-Sub audio connectors
Extruded aluminum frame with expanded cable raceways
DAW-friendly frame with deep armrest and rear shelf for monitors

Physical & Power Specifications
Console Width: Approx. 68–70 inches
Weight: Approx. 450–550 lbs (estimated)
Power Supply: Internal, <600W
Power Input: 110V / 230V auto-switching
Cooling: Passive, no fans required

Included Modules
24 Input Modules
Bus Master Modules (1–8)
Aux / Return Master Section
Cue / Matrix Output Module
Main Monitor and Main Mix Modules
Integrated Talkback Section

Studio Integration & Compatibility
Fully compatible with Dante AoIP networks and Dante Controller
Direct DAW integration via Ethernet
Supports Atmos music production and immersive workflows
Expandable via modular design
Custom configurations available upon request
